Hikvision DS-KIS603-P(O-STD) Video Intercom Complete Set

Main features

Door station

• standard PoE
• 2 MP HD camera
• noise reduction and echo cancellation
• access control functions
• tamper proof
• remote configuration via the web

Network indoor station

• 7 inch touch screen with a resolution of 1024 × 600
• standard PoE
• stores messages and recorded images on the TF card
• remote unlock via the client software or mobile phone

Client

• displays live videos from door stations and connected cameras
• supports wireless network

Technical specifications

System parameters

• operating system: embedded linux operating system
• operating method: one button
• flash: 32 m
• ram: 256 m

Video parameters

• camera: 2 MP HD camera
• night vision: IR supplement mode, 3 m
• features: BLC, DNR, true WDR
• field of view: horizontal 129°, vertical 75°
• video compression standard: H.264
• stream: 1080p @ 30 fps, 720p @ 25 fps
• resolution: 1920 × 1080p, 720p
• motion detection
• anti-flicker frequency: 50 Hz, 60 Hz

Audio parameters

• audio intercom: two-way audio communication
• audio input: built-in omni-directional microphone
• audio output: built-in loudspeaker
• audio compression standard: G.711 U
• audio compression rate: 64 kbit/s
• audio quality: noise reduction and echo cancellation

Access control parameters

• reading frequency: 13.56 MHz
• card type: mifare card
• relay(s): 1

Interfaces

• RS-485
• wifi: wifi 2.4 g
• debugging port: 1
• TF card: maximum 32 g
• alarm input: 4

General

• protection rating: IP65
• power supply: IEEE 802.3af standard PoE; 12 VDC
